Aqua Stop Fence Top Panel
$425.00
The Aqua Stop Fence Top Panel is a galvanised steel mesh accessory designed for Aqua Stop delineator installations where a fence-top configuration is required. Its 780 mm post centres are configured for Aqua Stop fitment, with a 1,975 mm long × 1,020 mm high panel weighing 18 kg.
Aqua Stop-Specific Fitment
Designed for Aqua Stop installations, with 780 mm post centres to suit the Aqua Stop configuration. The KI-1000 version uses different post spacing and is supplied as a separate product.
Galvanised Mesh Construction
The panel uses a 25 × 25 mm galvanised steel frame with 50 × 50 mm mesh and 2.5 mm wire, plus 305 mm long × 50 mm diameter fence legs.
Fence-top panel for Aqua Stop delineator installations
The Aqua Stop Fence Top Panel is a galvanised steel mesh accessory configured specifically for Aqua Stop installations. Its 780 mm post centres match the Aqua Stop fitment, allowing the delineator installation to be configured with a fence-top panel where required.
1,975 mm
Panel length
1,020 mm
Panel height
18 kg
Panel weight
Aqua Stop Fence Top Panel specifications
| Compatible product | Aqua Stop |
|---|---|
| Panel length | 1,975 mm |
| Panel height | 1,020 mm |
| Panel weight | 18 kg |
| Fence legs | 305 mm long × 50 mm diameter |
| Panel frame | 25 × 25 mm galvanised steel |
| Mesh | 50 × 50 mm × 2.5 mm wire |
| Post centres | 780 mm |
Designed for Aqua Stop
This version is configured specifically for Aqua Stop delineators, using 780 mm post centres.
KI-1000 uses a separate fence-top panel with different post spacing.
Planning larger panel quantities
40
Panels per pack
4
Pallet spaces per pack
2 high
Stacking configuration
Fence-top panels are packed in groups of 40. Packed dimensions and packed weight have not yet been supplied, so freight requirements should be confirmed for the actual order quantity and delivery location.
Aqua Stop Fence Top Panel FAQs
Quick answers about Aqua Stop Fence Top Panel compatibility, dimensions, construction and packing.
The Aqua Stop Fence Top Panel is a galvanised steel mesh accessory configured for use with Aqua Stop delineators.
It provides a fence-top configuration for Aqua Stop installations where additional vertical separation is required.
Yes. The Aqua Stop version uses post centres spaced at 780mm.
It should be treated as the Aqua Stop-specific fence-top panel rather than as a universal fence panel across the Barrier Systems range.
The two panels share the same basic panel dimensions, construction and weight, but their post spacing is different.
The Aqua Stop version has 780mm post centres, while the KI-1000 version has 930mm post centres. They are therefore supplied as separate product configurations.
Each panel is 1,975mm long and 1,020mm high.
The fence legs are 305mm long and 50mm in diameter.
Each Aqua Stop Fence Top Panel weighs approximately 18kg.
The panel uses a 25 × 25mm galvanised steel frame.
The mesh is 50 × 50mm with a 2.5mm wire size.
The Aqua Stop and KI-1000 fence-top panels use different post spacing.
The Aqua Stop version uses 780mm post centres, while the KI-1000 version uses 930mm post centres. The KI-1000 should therefore use its separately configured fence-top panel.
Fence-top panels are packed in groups of 40.
A pack requires four pallet spaces and the packs can be stacked two high.
Packed dimensions and total packed weight have not yet been confirmed.
For larger orders or delivery-sensitive projects, freight requirements should therefore be confirmed against the actual quantity and delivery location.
